26 Gallon Still with 3" Stainless Reflux Column

26 Gallon Still with 3" Stainless Reflux Column

  • $ 813.38


This 26 gallon still has it all! Comes with 3" stainless reflux column, (2) 2" element ports, for heating element adapters (adapters sold separately), tri clamp gasket and cover plate. This boiler can also be fired with a propane burner. The bottom of the boiler is flat and recessed.

Comes With:

  • 3" Tri Clamp with 3" Silicone Gasket for connecting the column to a still.
  • Commercial 3" face thermometer.
  • 3" Tri Clamp dephlegmator connection with 3" Tri Clamp and 3" Silicone Gasket.
  • Built in stainless Liebig condenser.
  • 1/2" Hose barb connections on the condenser and dephlegmator (pre-condenser) for cooling water.
  • Enough structured Copper Packing to fill the column.
  • Dephlegmator (pre-condenser) for increasing and controlling proof.
  • The column is 21" tall and the condenser is 30" long.
  • 1.5" drain valve with down spout
  • Carrying handles
  • 2" filler port with tri clamp, gasket and cap
  • 4" column connection
  • Top quality construction, with beautifully rounded curves
  • Built from heavy gauge 304 food grade Stainless Steel
  • Polished to a mirror finish inside and out
  • Base Diameter: 19 3/4"

DETERMINING TRI CLAMP SIZE

Tri Clamp sizes are determined by the outer diameter of the pipe or tubing, not the outer diameter of the flange or Tri Clamp itself. The flange of a Tri Clamp fitting typically has about a ½” inch greater diameter than the outside diameter of the pipe. This can become especially confusing when the Tri Clamp fitting has no pipe attached to it, as is the case with adapters, For instance, a 1.5" Tri Clamp to 1/2" hose barb adapter is not 1.5" inches in any dimension, but the Tri Clamp end will fit any other 1.5" Tri Clamp fitting.

If you have any doubts about what size Tri Clamp fittings your project needs, simply measure the outside diameter of the flange (dimension "B" below) and consult the chart below, or feel free to contact us .





Pipe Outer Diameter
A

Flange Outer Diameter
B

Pipe Inner Diameter
C

Tri Clamp Dimension Diagram

1"

1.98"

.87"

1.5"

1.98"

1.37"

2"

2.52"

1.87"

2.5"

3.05"

2.37"

3"

3.58"

2.87"

4"

4.68"

3.83"

6"

6.57"

5.78"

8"

8.57"

7.78"

10"

10.57"

9.69"

12"

12.57"

11.81"

Customer Reviews

Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
D
Davis
Great quality

Great quality, durable, and low maintenance. The only issue I’ve had is it takes 4.5-5 hours to get up to temperature over a banjo Burner, if anyone has any suggestions on a quicker method using propane I’d like to hear it. I’m not interested in electric since I start my spirit runs at 60abv
